Ubiquiti airFiber 5XHD Carrier Backhaul Radio

Buy Ubiquiti airFiber 5XHD Carrier Backhaul Radio from Tronik Gadgets Store — a high-capacity 5 GHz Point-to-Point (PtP) radio designed for long-range carrier-grade wireless backhaul. The airFiber 5XHD delivers over 1 Gbps throughput and exceptional link stability, making it ideal for ISPs, enterprise networks, and critical outdoor infrastructure. Its IP67 weatherproof design, GPS synchronization, and modular mounting options provide reliable performance in harsh environments, while flexible channel configuration ensures optimal spectrum utilization.

Key Features

• 5 GHz PtP carrier-grade radio with ultra-high throughput exceeding 1 Gbps
• Long-range connectivity up to 100+ km depending on antenna and conditions
• AES-256 encryption for secure wireless links
• Flexible channel widths from 10 MHz to 100 MHz with programmable uplink/downlink duty cycles
• GPS synchronization for multi-radio co-location and interference-free operation
• Passive PoE powered with included 24V, 1A gigabit PoE adapter
• IP67 weatherproof casing (with upgrade kit) for harsh outdoor environments
• airFiber X mount compatible (Rocket mount supported) for easy installation
• Compact, lightweight design with external magnetic GPS antenna

Specifications

• Dimensions: 224 × 82 × 48 mm (8.8 × 3.2 × 1.9”)
• Weight: 0.4 kg (0.8 lb)
• Networking Interfaces: 2 × GbE RJ45 ports
• Power Method: Passive PoE (4-pairs or 2-pairs configurable)
• Supported Voltage: 18–54V DC
• Max Power Consumption: 12W
• Frequency Range: 4800–6200 MHz (region-dependent)
• Max TX Power: 29 dBm
• Channel Bandwidth: 10/20/30/40/50/60/80/100 MHz selectable
• Modes: PtP Master/Slave
• Encryption: AES-256

Application Areas

• Long-range Point-to-Point (PtP) backhaul for ISPs and enterprise networks
• High-throughput outdoor wireless links for critical infrastructure
• Multi-radio deployments with GPS synchronization for spectrum efficiency
• Carrier-grade wireless networks requiring secure and reliable connections
• Outdoor deployment in harsh weather conditions and extreme temperatures
• Flexible, modular links with airFiber X or RocketDish antenna compatibility
