Ubiquiti Networks UAP-AC-LR Long Range Access Point

Buy Ubiquiti UAP-AC-LR Long Range Access Point from Tronik Gadgets Store and enjoy powerful long-range WiFi coverage, enterprise-grade performance, and seamless UniFi controller management. The UniFi AC LR is engineered with 802.11ac dual-band, offering 3×3 MIMO on 2.4GHz and 2×2 MIMO on 5GHz for higher throughput and superior coverage. With its innovative antenna design, this access point delivers symmetrical long-range links up to 183 meters, making it ideal for large homes, offices, hotels, schools, and high-density public areas. Easy to manage through the UniFi Controller, it supports RF optimization, guest access, WiFi analytics, and centralized configuration for scalable wireless deployments.

Features

Long-Range WiFi Coverage

Provides extended up to 183-meter range with an optimized antenna design for symmetrical, stable wireless links.

Dual-Band 802.11ac Performance

Simultaneous dual-band radios with 450 Mbps (2.4GHz) and 867 Mbps (5GHz) throughput.

Enterprise-Class WiFi Management

Fully managed via the UniFi Network Controller, offering RF mapping, monitoring, and multi-site visibility.

24V Passive PoE Support

Simplifies installation by allowing power and data over a single Ethernet cable using 24V Passive PoE.

High Client Capacity

Supports 250+ active users, ideal for high-density environments.

Guest Control & Portal Options

Includes captive portal, vouchers, Hotspot 2.0, and branded landing page options.

Advanced WiFi Technologies

Includes Band Steering, Fast Roaming (802.11r), BSS Transition (802.11v), and RRM (802.11k).

Specifications

• Dimensions: Ø175.7 × 43.2 mm
• WiFi Standard: WiFi 5 (802.11ac)
• Spatial Streams: 5
• Coverage Area: 185 m² (2,000 ft²)
• Max Client Count: 250+
• Uplink: 1× Gigabit Ethernet (GbE)
• Mounting: Ceiling, wall (mount included)
• Power Method: 24V Passive PoE
• Max Power Consumption: 6.5W

Performance

• MIMO:
  • 2.4 GHz: 3×3 DL MU-MIMO
  • 5 GHz: 2×2 DL MU-MIMO
• Max Data Rates:
  • 2.4 GHz: 450 Mbps
  • 5 GHz: 867 Mbps
• Antenna Gain:
  • 2.4 GHz: 3 dBi
  • 5 GHz: 3 dBi
• Max TX Power:
  • 2.4 GHz: 24 dBm
  • 5 GHz: 22 dBm

Hardware

• Networking Interface: (1) GbE RJ45
• Includes PoE Adapter: Yes
• Enclosure: Polycarbonate
• Weight:
  • Device: 240 g
  • With Mount: 315 g
• LED Indicators: System, status

Application Areas

• Large Homes requiring stronger, extended WiFi signals
• SMBs & Corporate Offices needing reliable coverage and roaming
• Hotels, Guesthouses & Hospitality offering secure multi-user WiFi
• Schools, Colleges & Campuses with high user density
• Public Hotspots & Outdoor Courtyards needing long-range connectivity
• Retail & Commercial Spaces using UniFi for centralized WiFi management
• Multi-floor Buildings where long-range penetration is essential
