Ubiquiti RocketDish Lightweight 5GHz 30dBi – RD-5G30-LW

Buy Ubiquiti RocketDish Lightweight 5GHz 30dBi from Tronik Gadgets Store and extend your wireless network with a high-performance carrier-class parabolic dish antenna. Designed for long-range Point-to-Point (PtP) links, the RocketDish RD-5G30-LW delivers exceptional 30 dBi gain and dual-polarity performance, enabling high-throughput, low-latency connectivity over distances of 30 km or more when paired with compatible Ubiquiti Rocket radios. Its lightweight, durable construction ensures reliable operation in harsh outdoor environments, while the built-in Rocket mount allows for easy installation without specialized tools. Ideal for wireless ISPs, enterprise backhaul, and long-distance connectivity projects.

Features

• High-Gain Performance
  30 dBi gain supports long-range links exceeding 30 km with compatible radios.
• Dual Linear Polarization
  Enhances data throughput and minimizes interference in crowded RF environments.
• Lightweight, Rugged Design
  Constructed to withstand wind speeds up to 200 km/h (125 mph) while reducing load on mounting structures.
• Plug-and-Play Rocket Integration
  Built-in Rocket mount allows direct attachment of Ubiquiti Rocket radios without additional tools.
• Precision Alignment
  Universal mounting bracket allows easy elevation and azimuth adjustments for optimal signal strength and link stability.
• Noise Immunity
  Extended dish reflector depth reduces co-location interference and maximizes throughput.

Specifications

• Frequency Range: 5.1 – 5.9 GHz
• Gain: 30 dBi
• Polarization: Dual Linear (Vertical & Horizontal)
• HPOL/VPOL Beamwidth: 5.8° (3 dB)
• Front-to-Back Ratio: 30 dB
• Cross-Pol Isolation: ≥ 35 dB
• Max VSWR: 1.6:1
• Dimensions: 650 × 650 × 386 mm (25.6 × 25.6 × 15.2″)
• Weight: 7.4 kg (16.31 lb) including mounting equipment
• Wind Loading: 790 N @ 200 km/h (178 lbf @ 125 mph)
• Wind Survivability: 200 km/h (125 mph)
• Mounting: Universal Pole Mount with Rocket Bracket and Weatherproof RF Connectors
• Certifications: ETSI EN 302 326 DN2, NDAA Compliant

Application Areas

1. Long-range Point-to-Point (PtP) wireless backhaul between towers or buildings.
2. High-capacity ISP network backhaul for delivering bandwidth to remote areas.
3. Enterprise outdoor networks requiring reliable, long-distance connectivity.
4. Carrier-class wireless bridges for high-throughput data links.
5. CCTV and surveillance network backhaul over extended distances.
