Ubiquiti UniFi NanoHD (UAP-NanoHD) Dual-Band 802.11ac Wave 2 Access Point

Buy Ubiquiti NanoHD access point, a high-performance, compact 802.11ac Wave 2 (WiFi 5) access point built for high-density wireless environments. Featuring 4×4 MU-MIMO on 5 GHz, 2×2 MU-MIMO on 2.4 GHz, and support for 200+ concurrent clients, the NanoHD delivers powerful enterprise-grade performance in one of the smallest UniFi AP form factors.

Designed for fast, reliable connectivity in offices, hotels, retail stores, classrooms, and high-density commercial spaces, the NanoHD offers seamless roaming, advanced network management, and full compatibility with UniFi PoE switches and standard 802.3af power.

For full installation steps, refer to the Installation Guide

Key Features

• 802.11ac Wave 2 (WiFi 5) Performance
  Supports combined wireless speeds up to 1.7 Gbps on 5 GHz and 300 Mbps on 2.4 GHz.
• High-Density Client Capacity
  Handles 200+ clients, ideal for business, retail, hospitality, and campus environments.
• 4×4 MU-MIMO on 5 GHz
  Allows simultaneous communication with multiple devices for improved throughput and efficiency.
• Ultra-Compact Form Factor
  Small, sleek design blends cleanly into modern interiors while delivering powerful performance.
• PoE Powered (802.3af)
  Works with any UniFi PoE switch or 48V PoE adapter (included).
• Advanced WiFi Optimizations
  Band steering, fast roaming (802.11r), radio resource management, wireless meshing, and beamforming.
• Captive Portal & Authentication
  Supports branded landing pages, vouchers, guest isolation, payment authentication, PPSK, and Hotspot 2.0.
• Centralized UniFi Management
  Configure and monitor through UniFi Network Controller (version 6.0.45+).

Technical Specifications

• Dimensions: Ø160 × 32.7 mm (Ø6.3 × 1.3 in)
• Weight:
  • Device: 300 g (10.6 oz)
  • With mount: 315 g (11.1 oz)
• Mounting: Ceiling, wall (Lite Mount included)
• NDAA Compliant: Yes
• Certifications: CE, FCC, IC, cULus, Anatel (06168-18-08356)

Wireless

• WiFi Standard: WiFi 5 (802.11ac Wave 2)
• MIMO:
  • 5 GHz: 4×4 (DL MU-MIMO)
  • 2.4 GHz: 2×2 (DL MU-MIMO)
• Max Data Rate:
  • 5 GHz: 1.7 Gbps
  • 2.4 GHz: 300 Mbps
• Antenna Gain:
  • 5 GHz: 3 dBi
  • 2.4 GHz: 2.8 dBi
• Max TX Power:
  • 5 GHz: 26 dBm
  • 2.4 GHz: 23 dBm
• Coverage Area: 140 m² (1,500 ft²)
• Max Client Count: 200+
• Max BSSIDs: 8 per radio
• Supported Channel Bandwidths: HT20/40, VHT20/40/80/160

Supported Data Rates

• 802.11ac: 6.5 Mbps – 1.7 Gbps (MCS0–MCS9, NSS1–4)
• 802.11ac VHT160: 58 Mbps – 1.7 Gbps
• 802.11n: 6.5 Mbps – 300 Mbps

Hardware

• Networking Interface: (1) Gigabit RJ45
• Maximum Power Consumption: 10.5 W
• Supported PoE Voltage: 44–57 V DC
• PoE Adapter Included: Yes
• Processor: Enterprise-grade platform with advanced radio management
• LED Indicators: System + Status

Operating Frequency

• US/CA:
  • 2.4 GHz: 2400–2472 MHz
  • 5 GHz U-NII-1/2A/2C/3: 5150–5850 MHz
• Worldwide:
  • 2400–2483.5 MHz
  • 5150–5725 MHz

Advanced Features

• Wireless Meshing
• Band Steering
• 802.11r Fast Roaming
• 802.11k Radio Resource Management
• 802.11v BSS Transition Management
• Advanced Radio Management
• Passpoint (Hotspot 2.0)
• Custom Captive Portal (branding, vouchers, payment-based login)
• Private Pre-Shared Key (PPSK)
• Guest Network Isolation
• Client Device Isolation
• WiFi Speed Limiting
• WiFi Scheduling
• RADIUS over TLS (RadSec)
• Dynamic VLAN Assignment

Ideal For

• High-density offices
• Hotels and hospitality networks
• Retail stores and shopping centers
• University classrooms & lecture halls
• Restaurants, coffee shops, and coworking spaces
• Enterprise and SMB wireless deployments
