UniFi U6 Mesh Pro Access Point (U6-Mesh-Pro)

Buy UniFi U6 Mesh Pro Access Point (U6-Mesh-Pro), a high-performance WiFi 6 (802.11ax) access point built for outdoor and semi-outdoor environments that demand reliable, high-capacity wireless coverage. With dual-band WiFi 6 technology, IPX6 weatherproofing, and advanced mesh capability, the U6-Mesh-Pro is ideal for hotels, campuses, enterprises, and outdoor public spaces.

Delivering speeds up to 2.4 Gbps on 5 GHz and 573.5 Mbps on 2.4 GHz, this access point supports 250+ concurrent clients and features dual Gigabit Ethernet ports for flexible deployment. Manage your network easily via the UniFi Access Point Controller for centralized configuration, monitoring, and optimization.

Key Features

• WiFi 6 (802.11ax) dual-band technology with up to 2.4 Gbps (5 GHz) and 573.5 Mbps (2.4 GHz) throughput
• 2×2 MIMO on both frequency bands for efficient multi-user performance
• Coverage area: 185 m² (2,000 ft²) supporting 250+ clients
• Dual Gigabit Ethernet ports for high-speed uplink and daisy chaining
• PoE-powered (42.5–57 V DC) with 9W max consumption
• Weatherproof IPX6-rated housing for outdoor durability
• Wall or pole mountable, mounts included
• Managed through UniFi Network Controller or UniFi mobile app

Technical Specifications

• UniFi U6 Mesh Pro (U6-Mesh-Pro)
• WiFi Standard: WiFi 6 (802.11ax)
• Dimensions: 343.2 × 181.2 × 60.2 mm (13.5 × 7.1 × 2.4 in)
• Coverage Area: 185 m² (2,000 ft²)
• Max Client Count: 250+
• Uplink: 2 × GbE RJ45 ports
• Mounting: Wall, Pole (mounts included)
• Weatherproof Rating: IPX6
• Power Method: PoE (42.5–57 V DC)
• Max Power Consumption: 9 W
• Weight: 819 g (1.8 lb)
• Operating Temperature: –30 to 60 °C (–22 to 140 °F)
• Operating Humidity: 5 – 95 % non-condensing
• Certifications: CE, FCC, IC, Anatel
• NDAA Compliant: Yes

Performance

• Spatial Streams: 4 (2×2 MIMO per band)
• MIMO Configuration:
  • 5 GHz – 2×2 DL/UL MU-MIMO
  • 2.4 GHz – 2×2 DL/UL MU-MIMO
• Maximum Data Rate:
  • 5 GHz – 2.4 Gbps (BW160)
  • 2.4 GHz – 573.5 Mbps (BW40)
• Antenna Gain:
  • 5 GHz – 8 dBi
  • 2.4 GHz – 8 dBi
• Max TX Power:
  • 5 GHz – 27 dBm
  • 2.4 GHz – 22 dBm
• Max BSSIDs: 8 per radio
• Channel Bandwidths: HT 20/40, VHT 20/40/80/160, HE 20/40/80/160 (MHz)

Supported Data Rates

• 802.11ax (WiFi 6): 7.3 Mbps – 2.4 Gbps (HE 20/40/80/160 MHz)
• 802.11ac (WiFi 5): 6.5 Mbps – 1.7 Gbps (VHT 20/40/80/160 MHz)
• 802.11n (WiFi 4): 6.5 Mbps – 300 Mbps (HT 20/40 MHz)

Features

• Wireless Meshing
• Band Steering
• 802.11v BSS Transition Management
• 802.11r Fast Roaming
• 802.11k Radio Resource Management (RRM)
• Advanced Radio Management
• Passpoint (Hotspot 2.0)
• Captive Portal with Custom Branding, Voucher and Payment Authentication
• Guest Network Isolation
• Private Pre-Shared Key (PPSK)
• WiFi Speed Limiting
• Client Device Isolation
• WiFi Scheduling
• RADIUS over TLS (RadSec)
• Dynamic RADIUS-Assigned VLAN

Hardware

• Networking Interfaces: 2 × GbE RJ45 ports
• Power Input: 42.5–57 V DC (PoE)
• Pole Mount Diameter: 25–63.5 mm (1–2.5 in)
• Enclosure Material: UV-stabilized polycarbonate
• Mount Material: Aluminum alloy and steel
• LED Indicators: System (White/Blue)

Software and Management

• Controller: UniFi Network (Version 8.1.127 and later)
• Management: Ethernet or Cloud via UniFi Controller
• Mobile App Support: iOS and Android
• Application: Managed through UniFi Access Point Controller

Operating Frequency

US/Canada:

• 2400 – 2472 MHz
• 5150 – 5850 MHz

Worldwide:

• 2400 – 2483.5 MHz
• 5150 – 5725 MHz

Ideal For

• Outdoor WiFi networks for enterprises, schools, and campuses
• Hotels, resorts, and hospitality networks
• Public WiFi zones, smart cities, and outdoor mesh installations
• Long-range Ubiquiti access point deployments

Shop for UniFi U6 Mesh Pro Access Point (U6-Mesh-Pro) at the best price in Kenya from TDK Solutions — your trusted supplier for Ubiquiti UniFi Access Points, Ubiquiti Access Point setup, and UniFi Access Point Controller integration.
Delivering WiFi 6 performance, long-range coverage, and enterprise reliability, the U6-Mesh-Pro is the perfect solution for powerful, scalable outdoor networks.

View Installation Guide for UniFi U6 Mesh Pro Access Point
