Image Sensor

1/2.7 inch CMOS

Effective Pixels

2560(H)×1440(V), 4MP

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s

S/N Ratio

>65dB

Minimum Illumination

0.02Lux/F2.0, 30IRE, 0Lux IR on

Fill Light Working Distance

40 m (131.2 ft)

IR On/Off Control

Auto; manual

IR LED Number

1

Pan/Tilt/Rotation Range

Pan: 0°–360°
Tilt: 0°–180°
Rotation: 0°–360°

Lens

Lens Type

Fixed-focal

Mount Type

M12

Focal Length

2.8 mm; 3.6 mm; 6 mm

Max. Aperture

F 2.0;F 2.0;F 2.0

Field of View

2.8 mm: 125° x 105° x 56°

(diagonal x horizontal x vertical)
3.6 mm: 104° x 87° x 47°

(diagonal x horizontal x vertical)
6 mm: 62° x 54° x 31°

(diagonal x horizontal x vertical)

Iris Type

Fixed iris

Close Focus Distance

2.8 mm: 0.7m (2.3 ft)

3.6 mm: 1.1m (3.6 ft)

6 mm: 2.7m (8.9 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8 mm

49.8 m (163.4 ft)

19.9 m (65.3 ft)

10 m

(32.8 ft)

5 m

(16.4 ft)

3.6 mm

64 m

(210.0 ft)

25.6 m (84 ft)

12.8 m (42 ft)

6.4 m

(21 ft)

6 mm

106.7 m (350.1 ft)

42.7 m (140.1 ft)

21.3 m (69.9 ft)

10.7 m (35.1 ft)

Video

Frame Rate

CVI:

PAL: 4M@25fps; 1080P@25fps;

NTSC: 4M@30fps; 1080P@30fps

AHD:

PAL: 4M@25fps;

NTSC: 4M@30fps

TVI:

PAL: 4M@25fps;

NTSC: 4M@30fps

CVBS:

PAL: 960H;

NTSC: 960H

Resolution

4M (2560 × 1440); 1080P (1920 × 1080); 960 H (960 × 576/960 × 480)

Day/Night

Auto switch by ICR

BLC

BLC/HLC/DWDR

WDR

DWDR

White Balance

Auto; manual

Gain Control

Auto; manual

Noise Reduction

2D NR

Smart IR

Yes

Electronic Defog

Yes

Mirror

Off/On

Privacy Masking

Off/On (8 area, rectangle)

Certifications

Certifications

CE (EN55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN55024:2010+A1:2015, EN 55035:2017, EN50130-4:2011+A1:2014)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Port

Video Output

Video output choices of CVI/TVI/AHD/CVBS by one BNC port

Power

Power Supply

12V ±30% DC

Power Consumption

Max 3.2W (12V DC, IR on)

Environment

Operating Temperature

-40°C to +60°C (-40°F to 140°F); <95% (non-condensation)

Storage Temperature

-40°C to +60°C (-40°F to 140°F); <95% (non-condensation)

Protection Grade

IP67

Structure

Casing

Mental front cover+plastic main body+mental bracket

Camera Dimensions

240.7 mm × 90.7 mm × 90.4 mm ( 9.48″ × 3.57″ × 3.56″ )

Net Weight

0.41 Kg (0.90 lb)

Gross Weight

0.62 Kg (1.37 lb)
